MNC360

MNC360 Features

PoC Mobile Radio

Mobile LTE GPS



The MNC360 is a push-to-talk over cellular (PoC) mobile radio designed for in-vehicle communication. With Hytera innovative design, it provides reliable, loud & clear voice service for various field communication scenarios. The simple-to-use design enables ease of radio installation, removal, and operation. Versatile accessories are available to meet requirement in different work environments. Working as a professional business-ready PTT mobile radio, MNC360 is the ideal group communication device for vertical markets.

Categories: , , Tags: , ,

Highlights of MNC360



Smooth Communication

Compared with regular smartphone, the two external LTE antennas on the MNC360 improve its RX sensitivity by 3 dB. The manual switch enables the MNC360 to always select the network with stronger signal strengths.

Loud and Clear Voice

The built-in 4-watt speaker comes with distortion suppression, howling suppression and noise cancellation technology, which enables the MNC360 to transmit loud and clear audio even with the window rolled down in construction sites or bustling street.

Flexibility and Adaptability

Paring with rich accessories, the MNC360 gives more freedom and flexibility for voice communications. With the Android system and standard APIs, the MNC360 is open for third-party apps to create an in-vehicle ecosystem for data application in the field.

Smart Design, Safe Driving

The MNC360 is a safety assistant providing over-speed alarm and fatigue driving alarm to ensure a safe trip. Keys on the MNC360 are automatically locked during driving, helping the driver focus more on the road and less on the radio.

Robust Design, Easy to Use

Compact and lightweight, the MNC360 perfectly fits into the limited space in the vehicle of almost all types. Aviation connector between remote microphone and main unit, robust design to provide reliable and stable connection under any operation scenarios.
Wireless Data Communication
LTE TDD-LTE:B38/B39/B40/B41(2496-2690MHz); FDD-LTE:B1/B2/B3/B4/B5/B7/B8/B12/B13/17/B20/B26/B28
WCDMA B1/B2/B3/B4/B5/B8
GSM 850/900/1800/1900MHz
WLAN 2.4GHz,802.11 b/g/n
NFC optional
Positioning GPS/GLONASS/BDS/AGPS



General
Dimensions(H×W×D) mm 170mm*66mm*39.3mm
Weight About 300g
Operating System Android 7.1
Memory 1GB RAM+8 GB ROM
Sensors Three-axis acceleration sensor
Peripheral Interface Micro USB 2.0;3.5 mm audio jackTwo LTE antenna portsGPS antenna connectorPower inlet10-pin aviation port
Display 2.0 inches
Card Slots 2*Micro-SIM
Operating Voltage 13.6±15%V DC



Environmental
Operating Temperature -20℃ ~ +60℃
Storage Temperature -40℃~+85℃
Dust & Water Protection IP54



Certification
Certification FCC/IC/CE



* Product images, specifications, features, and accessories shown on this page are subject to change due to ongoing technology upgrades and production improvements. To ensure you receive the correct product and compatible accessories, please contact the Hytera sales team for the latest information before placing an order. Hytera reserves the right to modify product details without prior notice.
